Chinese bicycle framesTitanium Cyclocross bike frame part-WTJ10-480

FOB Reference Price:Get Latest Price
5 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Material:
Titanium
Foldable:
No
Size:
48 - 52cm
Use:
Road Bicycles, cyclecross
Weight:
1.25kg
Place of Origin:
Fujian, China (Mainland)
Brand Name:
Waltly
Model Number:
WTJ10-480
Color:
Natural gloss
Surface:
Polishing and wiredrawing
Grade:
GR9
Feature:
Light weight
Package:
OPP and carton
Guarantee:
Lifetime
SupplyAbility
SupplyAbility:
200 Unit/Units per Month
Packaging & Delivery
Packaging Details
OPP bag with carton box
Port
XIAMEN
Lead Time :
35 days after order confirmation

Specifications

titanium Road bike part
1.Design for light off road use
2.Logo Graphic acceptable
3.Free drawing
4.full geometry size

Titanium 700C Road Bike part-WTJ10-485



Frame typeseat tubeeffective
top tube
chain
stay
head
tube
head
tube
angle
seat
tube
angle
BB
drop
C-TC-C
(A)(B)(C )(D)(E)(F)(G)(H)
3AI-2.5V Ti 482 440.7 521.4 403 100 72.5 75 68
Note: all measurements in millimeter (mm) except head tube and seat tube angles in degrees.


Frame material3AI-2.5VI seamless tube
Head tubefor 1 1/8" fork,standard non-integrated headset
Top tube(34.9*0.9*0.7*0.9)mm OD  ovalized
Seat tube(34.9*0.9*0.7*0.9)mm OD, GOOD FOR 31.8mm SEAT POST
Down tube(44.5)OD,0.9mm;double butted
Seat stay(16*0.9)mm;
Chain stay(26*32)0.9mm;
Bottom bracket1.37"x24TPI   (BB30/BSA/PF30 Available)

 Cyclo Cross2-1.jpg
